HK AUDIO Linear SUB 2000A
CHF1'649.00
HK AUDIO Linear SUB 2000A
Availability: <div class="">Habituellement sous 48h</div>
SKU: HK_AUDIO_Linear_SUB_2000A_5977
Category: Hauts-Parleurs Actifs
- Description
- Additional information
- Brand
Description
L SUB 2000 A
Powered subwoofer, 1200W, 2x 12?, 2.5? voice coil, 135 dB max. SPL, 110/ 120Hz variable x-over frequency, Speakon Out, birch multiplex, 2 x M20 threading
Description
L SUB 2000 A ??A LOW-END BOOST FOR THE LINEAR SERIES
Equipped with a sixth-order double bandpass crossover, the L Sub 2000 A is the perfect reinforcement for L5 tops. Its lowend performance in the 50-120 Hz range is most impressive. It sports two 12? high-excursion woofers. This speaker?s 2.5? voice coil comes with a state-of-the-art cooling system and a dual spider suspension to keep it perfectly centered. A newly developed 1,200-watt, Class-D power amp drives these speakers
- High-power subwoofer
- 1200 Watt class D amping
- 2 x 12? speakers with 2.5? voice coil
- 133 dB Max SPL Peak @ 10% THD (halfspace)
- Rugged birch multiplex?wooden enclosure
- Swichtable x-over frequency
- Multifunctional handles
- Ideal add-on to LINEAR 5 mid/high units
- Can also be used in combination with LINEAR 3 mid/high units
Techn. Data
Max SPL | 132 dB half space (@ 10% THD) |
Max SPL peak | 133 dB half space (@ 10% THD) |
Max SPL calculated | 135 dB half space |
Frequency response +/- 3 dB | 49 Hz ? X-Over |
Frequency response -10 dB | 39 Hz ? X-Over |
Power Rating | 1200 W |
Amplifier | Class D |
Active protection circuits | Undervoltage-Protection, Thermoprotection, Short-Circuit Protection, Overcurrent-Protection, Subsonic 24dB/Oktave, Peak Limiter |
LF Speaker | 2x 12″ featuring advanced cooling technology |
Cut-off Frequency active | 100 Hz / 120 Hz variable with 24 dB/oct. |
Connections | 2x XLR?1/4″-Combo In, 2x XLR-Thru, 2x XLR-Mid/High Out |
Input Sensitivity | +4 dBu @ Gain center-notched |
Pole mount | 1x M20 (K&M) |
Handles | 4x HK Audio MultiGrip |
Enclosure | Birch multiplex |
Grille | 2 mm metal grille backed with black acoustic foam |
Finish | Acrylic enamel, black |
Optional accessories | Protective cover, M20 Distance Pole Add-On, tilt unit, 100 mm casters |
Dimensions (WxHxD) | 51 x 81 x 61 cm |
Weight | 47.5 kg / 104.7 lbs |
Additional information
Weight | 50 kg |
---|
