Description
ecording Media 16 MB to 2 GB SD cards 4 to 32 GB SDHC cards 64 to 512 GB SDXC cards
Input Connectors Input 1-4: XLR-1/4″ / 6.35 mm combo jacks
Input 5-6: 1/8″ / 3.5 mm stereo mini jack
Input Gain XLR (Mic): +10 to +75 dB
TRS (Line): -10 to +55 dB
Mini Jack Input: -10 dBV (Level: -10 dBV setting), +4 dBu (Level: +4 dBu setting)
Input Impedance XLR (Mic): 3.0 kOhms
TRS (Line): 22 kOhms
Mini Jack Input: 10 kOhms or more
Maximum Input Level XLR (Mic): +14 dBu (at 0 dBFS, limiter ON)
TRS (Line): +24 dBu (at 0 dBFS, limiter ON)
Mini Jack Input: -10 dBV (Level: -10 dBV setting), +24 dBu (Level: +4 dBu setting)
Phantom Power +24 / +48 V 10 mA maximum for each channel
THD XLR (Mic): 0.009% max (1 kHz, 22 Hz – 22 kHz BW, Input Gain min, -10 dBu input)
TRS (Line): 0.010% max (1 kHz, 22 Hz – 22 kHz BW, Input Gain min +10 dBu input)
EIN −127 dBu or less (A-weighted, +75 dB input gain, 150 Ohms input)
Frequency Characteristics 10 Hz – 80 kHz +0.5/−1 dB (192 kHz sampling rate)
Dynamic Range ADC 120 dB typical (−60 dBFS input, A-weighted)
Crosstalk −90 dB or less (between adjacent channels, 1 kHz)
Mic Input ZOOM mic-capsule input (use disables Inputs 1/2)
Output Connectors Main: Balanced XLR (2-pin hot)
Sub Output: 1/8″ / 3.5 mm
Headphone: 1/4″ / 6.35 mm unbalanced stereo jack
Output Impedance Main: 150 Ohms or less
Sub Output: 1 kOhms or less
Headphone: 15 Ohms or less
Reference Output Main: −10 dBV, 1 kHz, 600 Ohms load
Sub: −10 dBV (Normal Output Type), −40 dBV (Mic Output Type), 1 kHz, 10 kOhms load
Maximum Output Level Main: +10 dBV, 1 kHz, 600 Ohms load
Sub Output: +10 dBV (Normal Output Type), −20 dBV (Mic Output Type), 1 kHz, 10 kOhms load
Headphone: 100 + 100 mW (32 Ohms load)
Dynamic Range DAC 106 dB typical (−60 dBFS input, A-weighted)
Recording Formats WAV: 44.1, 47.952, 48, 48.048, 88.2, 96, 192kHz, 16/24-bit, mono/stereo/2-10 ch poly, BWF and iXML
MP3: 128, 192, 320 kbps, 44.1/48 kHz, ID3v1 tags
# Of Simultaneous Record Tracks WAV: 8 (6 inputs + stereo mix)
MP3: 2
Recording Time 32 GB: 30:51:00 (48 kHz/24-bit stereo WAV), 7:42:00 (192 kHz/24-bit stereo WAV)
Timecode Connector: BNC
Modes:Off, Int Free Run, Int Record Run, Int RTC Run, Ext, Ext Auto Rec (audio clock can be synchronized to timecode)
Frame Rates: 23.976ND, 24ND, 25ND, 29.97ND, 29.97D, 30ND, 30D
Precision: ±0.2 ppm
Supported Input Levels:0.2 to 5.0 Vpp
Input Impedance: 4.3 kOhms
Output Level: 3.0 Vpp ±10%
Output Impedance: 50 Ohms or less
Power Batteries: 8 AA
Zoom AD-19 12V AC Adapter
DC-HIROSE Cable HIROSE HR10A-7R-4S 4-pin connector (1 pin: −, 4 pin: +), 9-16 V
Battery Life (Recording) Continuous Recording Time: When recording 2 channels at 48 kHz/16-bit without headphones
Alkaline Batteries: 9.5 hours or more
NiMH (2450mAh): 11.5 hours or more
Lithium Batteries: 17.5 hours or more
Continuous Recording Time: When recording 8 channels at 48 kHz/24-bit with headphones
Alkaline batteries: 9.0 hours or more
NiMH (2450mAh): 10.5 hours or more
Lithium Batteries: 16.5 hours or more
Continuous Recording Time: When recording 8 channels at 192 kHz/24-bit with headphones, phantom power, and display backlighting
Alkaline Batteries: 2 hour or more
NiMH (2450mAh): 3.5 hours or more
Lithium Batteries: 6 hours or more
Display 1.9″ / 48.3 mm Monochrome LCD: 128 x 64
USB USB: Mass Storage Option
Class:USB 2.0 high speed
USB: Multitrack audio-interface operation (driver required for Windows, not required for Mac)
Class:USB 2.0 High Speed
Specifications: 44.1, 48, 96 kHz, 16/24-bit, 6-in/4-out
USB: Stereo Mix audio-interface operation (no driver required)Class: USB 2.0 Full Speed Specifications: 44.1, 48 kHz, 16-bit, 2-in/2-out
Note: iPad audio-interface operation supported (Stereo Mix mode only)
Dimensions (W x D x H) 7.0 x 5.5 x 2.1″ / 177.8 x 139.7 x 53.3 mm
Weight 2.3 lb / 1.0 kg
Packaging Info
Package Weight 5.1 lb
Box Dimensions (LxWxH) 11.6 x 10.4 x 4.9″
Additional information
Weight | 1 kg |
---|
